Simple and customizable Syslog server in python

on
syslog_server_python

Skill - Simple and customizable Syslog server in python

Table of Contents

In this post we will create a Syslog server in python that listens for Syslogs over the network and logs them to file storage

What is Syslog

  • Syslog is a standard protocol to send logs or event messages to a logs storage server
  • A blog-post on setting a third party simple Syslog server in Windows or Ubuntu like systems can be found here

Use cases

  • A Syslog server written in python can be used for the following
    • Create a Syslog storage solution with out installing a third party software
    • Perform ad-hoc automation upon receiving Syslog messages
    • Create data pipelines

Minimal Syslog server in python

  • Running the following python code listens for UDP requests over a specified host and port and then just logs them into a file named logs.log using python logging and socketserver modules
## Minimal Syslog Server in Python.
import logging
import socketserver

LOG_FILE_PATH = 'logs.log'
HOST, PORT = "0.0.0.0", 514

logging.basicConfig(level=logging.INFO, format='%(message)s', filename=LOG_FILE_PATH, filemode='a')

class SyslogUDPHandler(socketserver.BaseRequestHandler):
	def handle(self):
		data = bytes.decode(self.request[0].strip())
		# socket = self.request[1]
		print( "%s: " % self.client_address[0], str(data))
		logging.info(str(data))

if __name__ == "__main__":
	try:
		server = socketserver.UDPServer((HOST,PORT), SyslogUDPHandler)
		server.serve_forever(poll_interval=0.5)
	except (IOError, SystemExit):
		raise
	except KeyboardInterrupt:
		print ("Crtl+C Pressed. Shutting down.")
  • The handle function inside the SyslogUDPHandler class has access to the Syslogs upon receiving by the socketserver.

Testing the Syslog server by sending logs to it

  • Logs can be sent to Syslog server using python
  • SysLogHandler class in python logging module can be used for this purpose as shown in the below example
import logging
from logging.handlers import SysLogHandler

sysloghHandlr = SysLogHandler(address=("127.0.0.1", 514))

logger = logging.getLogger()
logger.addHandler(sysloghHandlr)
logger.setLevel(logging.INFO)

logger.info("This is a sample info message")
logger.warning("Sample warning message")
  • By running the above script, Syslogs can be sent to a Syslog server. In this example, two Syslogs of levels INFO and WARNING are sent to a Syslog server listening over UDP 514 port with hostname ‘127.0.0.1’ (localhost)

Syslog server with log rotation and compression

"""
Syslog Server for collecting logs
and saving in a rolling time log files
"""
import json
import logging
import os
import socketserver
import zipfile
from logging import LoggerAdapter
from logging.handlers import TimedRotatingFileHandler

# load configuration from json file
appConfig = json.load(open('config.json'))

logFilePath = appConfig["logFilePath"]
HOST, PORT = appConfig["host"], appConfig["port"]
backUpCount = appConfig["numFilesRetention"]
fileRollingHrs = appConfig["rollOverHours"]


def getFileLogger(name: str, fPath: str, backupCount: int, numRollingHrs: int) -> LoggerAdapter:
    # create a logger object and set minimum log level
    logger = logging.getLogger(name)
    logger.setLevel(logging.INFO)

    # create log handlers
    fileHandler = TimedRotatingFileHandler(
        fPath, backupCount=backupCount, when='h', interval=numRollingHrs)
    # streamHandler = logging.StreamHandler()

    # setup log rotation for file based log handler
    fileHandler.namer = lambda name: name.replace(".log", "") + ".zip"

    # setup log file compression with custom log rotation method
    def rotator(source, dest):
        zipfile.ZipFile(dest, 'w', zipfile.ZIP_DEFLATED).write(
            source, os.path.basename(source))
        os.remove(source)
    fileHandler.rotator = rotator

    # setup log formatting for log handler
    logFormatter = logging.Formatter("%(message)s")
    fileHandler.setFormatter(logFormatter)
    # streamHandler.setFormatter(logFormatter)

    # add log handler to the logger object
    logger.addHandler(fileHandler)
    # logger.addHandler(streamHandler)

    # create logger adapter with the logger object to inject extra data if required
    loggerAdapter = logging.LoggerAdapter(logger, extra={})

    # return the logger adapter
    return loggerAdapter


logger = getFileLogger(
    "app_logger", logFilePath, backUpCount, fileRollingHrs)


class SyslogUDPHandler(socketserver.BaseRequestHandler):
    def handle(self):
        data = bytes.decode(self.request[0].strip())
        # socket = self.request[1]
        strData = str(data)
        # print("%s : " % self.client_address[0], strData)
        logger.info(strData)


if __name__ == "__main__":
    try:
        server = socketserver.UDPServer((HOST, PORT), SyslogUDPHandler)
        server.serve_forever(poll_interval=0.5)
    except (IOError, SystemExit):
        raise
    except KeyboardInterrupt:
        print("Crtl+C Pressed. Shutting down.")
  • The above python file server.py runs like a Syslog server. It requires a configuration file named config.json where all the configuration can be specified. The config.json file should be in the same folder as server.py
{
    "_comment": "This is the config.json file",
    "logFilePath": "app_log.log",
    "host": "0.0.0.0",
    "port": 514,
    "numFilesRetention": 400,
    "rollOverHours": 24
}
  • The above python script will listen for Syslog messages and write them into a log file. The log file location and Syslog server listening port can be configured in config.json file
  • The log files will be rotated and compressed after the configured number of hours. The number of hours can be configured in the config.json file
  • The number of files after which the old log files can be deleted can be configured in the config.json file
  • A detailed blog-post on logging in python with log rotation and compression can be found here
  • The above example rotates logs based on time. But this code can be customized to make the logs rotate based on size using the RotatingFileHandler class

Run the Syslog server as a windows background service with nssm

  • Create a batch file named run_server.bat and write the following in it
REM batch script to run the syslog server
python run_server.py
  • Use nssm to run this batch script as a windows background service
  • Open the command prompt in administrative mode and run the command nssm install syslog_server_python
  • After the service is installed, open services.msc and make the startup type of this service as ‘Automatic’, so that the service will start upon system reboot
  • A blog-post on using nssm to run a script as a windows background service can be found here

Conclusion

  • The python based Syslog server once setup, is quite robust without many external python library dependencies and can be used for small scale monolithic deployments
  • However, for complex and critical Syslog server deployments, battle-tested and robust syslog server solutions like rsyslog can be used

Video

The video for this post can be seen here
